TY-LS4060C
- Product name： TY-LS4060C
- Tel：?15976855411
-
Product Details
TY-LS4060C
product description
▲ Main parameters
| model | TY-LS4060C | Fine tuning | ±10 | |
| Maximum printing area (mm) | 400*600 | Maximum printing times Hr | 1000 | |
| Table area (mm) | 500*700 | Printing pressure kgf/c㎡ | 0.6 | |
| Maximum screen frame installation (mm) | 600*950 | Air consumption (liter/turnover) | 4.2 | |
| Platform accuracy (mm) | ±0.05 | Power (V)/Power (KW) | 220/1.9 | |
| Printing thickness (mm) | ≤50 | Volume LxBxH (mm) | 1020*900*1640 |
▲ Applicable scope:
Various kinds of glass, compact disc, credit card, PCB, flexible circuit board, film, keyboard, acrylic, window lens, electronics, PVC, PET, PC and other products with different thickness and small area.
▲ Main performance
1) Vertical structure, cast aluminum alloy beam, electric lifting, servo printing to ensure the smooth operation of the whole machine.
2) PLC program control circuit, imported electronic and electrical components, pneumatic components.
3) Stainless steel printing platform, X-axis and Y-axis precision fine-tuning handles are easy to adjust, and the color registration is accurate.
4) The exquisitely designed cast aluminum alloy head, the precision cylinder combination and the hardened guide rail slide block guide the plate lifting device, which is convenient to replace the screen and wash the plate.
5) Man-machine interface operating system
6) Independent driving source for printing and screen lifting, coordinated actions, and more stable servo printing.
7) The new concept of humanized operation design, the whole machine is equipped with safety protection devices.
